Hella 1468-24V LED Reversing Lamp - Horizontal Mount 24V

Hella 1468-24V LED Reversing Lamp - Horizontal Mount 24V

Hella 1468-24V LED Reversing Lamp - Horizontal Mount 24V

Mounting: Suitable for horizontal and vertical mounting.

Power Consumption

Stop: 3W

Rear Position: <0.5W

Protection

• Reverse polarity protection.
• IP 6K7 (Protection against dust and temporary water immersion)
• IP 6K9K (Protection against dust and high-pressure/steam jet cleaning)

Cable Length: Pre-wired with 0.3m cable.

Lens Material: Grilamid®

Compliance

ADR 49/00

LED-Reverse Light - Strip Lamp low profile - 24V - Screw Connection/mounting - for horizontal fastening - Plug: open cable ends - Quantity: 1

Features

• Lamp Type: LED - Number of LEDs: 10 - Power consumption: 3W
• Light functions: 1 - with reverse light (LED) - Lens Colour: transparent - Fitting Position: Rear
• Registration Type: ADR/GGVS - Fulfils ECE norm.: R23 - Prot.type (IP Code): IP6K7/IP6K9K
• Synthetic Material Housing - Housing Colour: Black - Diffusing Lens Material: Nylon
• Length: 283mm - Width: 11mm - Height: 25mm

Specifications

• Part number: 1468-24V
• Hella number: 2ZR 980 889-201
• Barcode (EAN): 9416325236023
• Brand: Hella
• Mounting Type: Screw Connection / mounting
• Fastening Type: for horizontal fastening
• Light Design: LED
• Lamp Type: LED
• Voltage: 24 V
• Fitting Position: Rear
• Height: 25 mm
• Width: 11 mm
• Length: 283 mm
• Light Function: with reverse light (LED)
• Number of light functions: 1
• Registration Type: ADR/GGVS approved
• fulfils ECE standard: R23
• Power Consumption: 3 W
• Number of LEDs: 10
• Housing Type: Synthetic Material Housing
• Housing Colour: black
• Lens Material: Nylon
• Lens Colour: transparent
• Plug Type: open cable ends
• Version: low profile
• Reverse polarity protection: Yes
• Protection Type per ISO 20653: IP6K7 / IP6K9K
• Product line: Strip Lamp

Assy./disassy. by qualified personnel required!
