Hella 2XD958130661 LED Work Strip Light - Red

Hella 2XD958130661 LED Work Strip Light - Red

Hella 2XD958130661 LED Work Strip Light - Red

LED-Worklight - Light Bar LB470 R - 12/24V - 2000lm - Bolted/mounting - Suspended/Vertical - Spot illumination - Light colour: Red - Cable: 2500mm - Plug: open cable ends

It is essential to protect employees from the potential dangers of moving machinary. The BL470R LED warning lamp features a powerful red safety strip of light that indicates a no-go zone to keep staff and pedestrians at a safe distance so ideal for use on forklifts, and earth moving equipment which need surrounding work space to be identified by a no-go line. Providing unmatched corrosion resistance due to an innovative thermally conductive polymer housing and the toughness of a UV, chemical and impact resistant Grilamid lens, the BL470R is the natural choice when exceptional durability and long term reliability in demanding environments is needed. The BL470R warning lamp also features MultivoltTM circuitry making it suitable for 12V or 24V DC systems. Completely sealed and covered by a 5 year warranty for complete peace of mind.

Features

• Lamp Type: LED - Power consumption: 25W
• Patterned diffusing lens - Lens Colour: Crystal clear
• Fulfils ECE norm.: R10 - Prot.type (IP Code): IP6K7/IP6K9K
• Synthetic Material Housing - Housing Colour: Black - Light colour: Red
• Width: 528mm - Height: 72mm - Depth: 67mm
• Communication by using light
• Projects a red strip to indicate a no-go zone_x000D_
• Increases safety by indicating danger zone
• Low power consumption of less than 25W
• Fully sealed against dust and moisture

Specifications

• Part number: 2XD958130661
• Hella number: 2XD 958 130-661
• Barcode (EAN): 9416325247791
• Brand: Hella
• Mounting Type: Bracket mounting
• Light Design: LED
• Lamp Type: LED
• Voltage: 12 / 24 V
• Height: 44 mm
• Overall Height: 72 mm
• Width: 528 mm
• Depth: 67 mm
• Light Distribution: Spot Illumination
• Light colour: red
• fulfils ECE standard: R10
• Plug Type: open cable ends
• Protection Type per ISO 20653: IP6K7 / IP6K9K
• Luminous Flux: 2000 lm
• Power Consumption: 25 W
• Cable Length: 2500 mm
• Housing material: Plastic
• Housing Colour: black
• Lens Material: PC (Polycarbonate)
• Lens Type: patterned lens
• Lens Colour: Crystal clear
• Registration Type: ECE approved / RCM approved
• Voltage from: 9 V
• Voltage to: 33 V
• Temperature range from: -40°C
• Temperature range to: 60°C
• Shape: Slim
• Reverse polarity protection: Yes
• Weight: 1100 g
• Product line: Light Bar LB470

Assy./disassy. by qualified personnel required!
